Alcatel-Lucent OmniSwitch 6850

Overview
Key Features
Specification
Download

The Alcatel-Lucent OmniSwitch 6850
(OS6850) Stackable LAN Switch (SLS)
family addresses the needs of modern
enterprise and triple-play networking
with flexible, configurations; powerover-
Ethernet, high availability, firstpacket
wire-speed performance, and
dramatically improved network
response time.

Alcatel-Lucent

The OmniSwitch 6850 series, similar to the existing Alcatel-Lucent OmniSwitch products, uses the Alcatel-Lucent Operating System (AOS), which ensures an easy and economical way to upgrade or deploy a new Ethernet network. The flexible configuration options offered by the OmniSwitch 6850 family makes it suitable for a small/medium network in the core or at the edge of a large network. Also, the OmniSwitch 6850 protects your investment with native support of IPv4 and IPv6 switching.

THE SWITCHES PROVIDE:

Choice of PoE (Power-over-Ethernet) and non-PoE models
Triple-speed 10/100/1000 interfaces and 10Gig uplinks
Fast Ethernet interfaces upgradeable to Gigabit via a software license key without any network reconfiguration
Gigabit fiber interfaces (SFP) supporting 100BaseX, dual-speed and 1000BaseX optical transceivers
Stacking capability for virtual chassis redundancy
Power supply choice (AC, DC, PoE) for flexible deployment
IPv4 and IPv6 layer-2 and layer-3 switching for future-proof investment
Advanced quality of service (QoS) to support mission-critical and triple-play applications

Specifications

Indicators	EMC	IEEE Standards
PER PORT LEDS • 10/100/1000: PoE, link/activity • SFP: link/activity • XFP: link/activity	• FCC CRF Title 47 Subpart B (Class A limits. Note: Class A with UTP cables) • VCCI (Class A limits. Note: Class A with UTP cables)	• IEEE 802.1D (STP) • IEEE 802.1p (CoS) • IEEE 802.1Q (VLANs) • IEEE 802.1QinQ(VLAN stacking) • IEEE 802.1ag (Connectivity Fault Management)
SYSTEM LEDS • Switch ID (indicates the stack ID of the unit in the stack: 1 to 7) • System (OK) (chassis HW/SW status) • PWR (primary power supply status) • PRI (virtual chassis primary) • BPS (backup power status)	• CE marking for European countries (Class A. Note: Class A with UTP cables) • EN 55022: 1995 (Emission Standard) • EN 61000-3-3: 1995 • EN 61000-3-2: 2000 • EN 55024: 1998 (Immunity Standards) • EN 61000-4-2: 1995+A1: 1998 • EN 61000-4-3: 1996+A1: 1998	• IEEE 802.1s (MSTP) • IEEE 802.1w (RSTP) • IEEE 802.1X (Port Based Network Access Protocol) • IEEE 802.3i (10BaseT) • IEEE 802.3u (Fast Ethernet) • IEEE 802.3x (Flow Control) • IEEE 802.3z (Gigabit Ethernet) • IEEE 802.3ab (1000BaseT)
Physical Dimensions (WxDxH)	Safety Agency Certifications	Weight
CHASSIS SIZE (WITHOUT POWER SUPPLY OR PS SHELF) • 17.32 x 10.63 x 1.73 in (44.0 x 27.0 x 4.4 cm)	• US UL 60950 • IEC 60950-1:2001; all national deviations • EN 60950-1: 2001; all deviations • CAN/CSA-C22.2 No. 60950-1-03	CHASSIS WITHOUT THE POWER SUPPLY • OS6850-P24 and -P24L 8.62 lb (3.91kg ) • OS6850-P24X 8.86 lb (4.02 kg ) • OS6850-P48and -P48L 9.39 lb (4.26kg )
TOTAL SIZE INCLUDING POWER SUPPLY'S SHELF AND MOUNTING EARS • 19.00 x 17.56 x 1.73 in (48.2 x 44.6 x 4.4 cm)	Audio 1 x 16 Watt	POWER SUPPLIES • 510W AC 5.71 lb (2.59kg ) • 360W AC 3.22 lb (1.46kg ) • 126W AC 2.45 lb (1.11kg ) • 120W DC 2.09 lb (0.95kg )
EARS,WITHOUT POWER SUPPLY OR PS SHELF) • 19 x 10.63 x 1.73 in (48.2 x 27.0 x 4.4 cm)
