LCD Panel Type
|
55"
|
Display Area
|
54.6"
|
Aspect Ratio
|
16 :9
|
Native Resolution
|
1920 x 1080 (FHD)
|
Pixels (H x V x 3)
|
6,220,800
|
VIDEO
|
Max Input Resolution
|
1920 X 1080@ 60Hz (RGB,HDMI/DVI)
|
Recommended Resolution
|
1920 X 1080 @ 60Hz (RGB, HDMI/DVI)
|
H-Scanning Frequency
|
30 ~ 83kHz (RGB, HDMI/DVI)
|
V-Scanning Frequency
|
56 ~ 75 Hz (RGB), 60 Hz (HDMI/DVI)
|
REAR INPUTS
|
Component Video
|
Yes, 1 Hi-Res
|
PC Input via 15-Pin Sub "D"
|
Yes, 1/ 1
|
Composite Video Input/Output
|
Yes, 1 / 1
|
Audio Output
|
Yes
|
Audio Inputs
|
Yes, 2 Plus PC Sound
|
AUDIO
|
Auto Volume
|
Yes
|
Balance
|
Yes
|
Audio Power
|
20W (10W x 2)
|
Speaker On/Off
|
Yes
|
Clear Voice II
|
Yes
|
Sound Mode
|
Standard / Music / Cinema / Sports / Game
|
Video Compatibility
|
NTSC, PAL, SECAM
|
SPECIAL FEATURES
|
Temperature Sensor
|
Yes
|
Cooling FAN
|
Yes
|
Split Zoom (Self Video Wall, Max 5x5)
|
Yes (adjusts for bezel width)
|
Brightness/Contrast
|
Yes
|
Position/Size
|
Yes
|
Auto Config/Phase
|
Yes
|
ISM Method
|
Normal/White Wash/Orbiter/Inversion
|
Time
|
Clock / On/off Timer / Sleep Timer / Auto Off,
Power on Delay
|
CABINET
|
Color
|
Black
|
Bezel Width
|
18.9mm
|
Monitor Dimension (W x H x D)
|
49.2" x 28.4" x 4.1"
|
Weight
|
78.5 lbs.
|
Packed Weight
|
95.7 Ibs.
|
POWER
|
Power Supply
|
100 - 240V~, 50/60Hz
|
Power Type
|
Built-in Power
|
Power Switch
|
No
|
STANDARD (CERTIFICATION)
|
Safety
|
UL / c-UL / CB scheme / TUV
|
EMC
|
FCC Class "B" / VCCI / C-tick / CE / KCC
|
Erp/ENERGY STAR 5.0
|
Yes/Yes
|
RoHS Compliant
|
Yes
|
UPC CODE
|
7 19192 18768 9
|
