PANEL
|
Operating System
|
Windows® 8 Pro |
| CPU |
The 4th Generation Intel® Core™ i3/i5/i7 Processor Socket LGA
Intel® Q87 |
| Chipset |
Intel® Q87
Support Intel® vPro Technology |
| Graphics |
Intel® HD Graphics |
| Memory |
4 x DIMM dual channel DDR3 1600MHz
Support max.32GB |
| Expansion Slots |
1 x PCI / 1 x PCI-e x 1 / 1 x PCI-e x 16 |
| Serial ATA |
6 x SATA III |
| Storage |
Support up to 2TB (SATA 7200 RPM) |
| Drive Bays |
2 x 5.25" (External)
1 x 3.5" (External)
2 x 3.5" (Internal) |
| LAN / LAN Chip |
Intel ® WGI217LM GB LAN
Support Wake On Lan function |
| Audio |
High-Definition Audio, 6 Channels |
| Interface Front I/O Port Rear I/O Port |
2 x USB 2.0 / 2 x USB 3.0 / 1 x Microphone / 1 x Headphone 4 x USB 2.0 / 2 x USB 3.0 / 2 x PS/2 / 1 x DVI-I / 1 x D-Sub (VGA Out) / 2 x Display
Port / 1 x RJ45 LAN / 1 x 6 Channel Audio (3 ports) / 1 x Parallel Port (optional) / 1
x COM Port (Serial Port) (optional) |
| Optical Drive |
DVD RW 8X |
| Power Supply |
Peak 350W / Peak 350W 80 Plus (Optional)
500W(Optional) |
| Dimension (mm) W x H x D |
180 x 364 x 404 mm |
| Dimension (mm) with Carton W x H x D |
295 x 490 x 520 mm |
| Weight with Carton (Kg) |
13.5 kgs |
| Accessories
|
1 x Keyboard (USB/PS2) / 1 x Mouse (USB/PS2) / 1 x Warranty Card / 1 x Power
Cord / 1 x User Manual (QIG) / 1 x Driver CD / 1 x Recovery CD (ship with OS) / 1 x
Mouse Pad |
| Software |
Anti-virus trial / Office trial |
| Certifications |
BSMI, CB, CE, FCC, UL, CCC, Energy Star, EPEAT , CECP, C-Tick |
| ASUS Utility |
ASUS Business Manager(including Intel SBA) *2 / ASUS Remote Management /
ASUS PC Diagnostics Tool / F9 One Key Restore / ASUS WebStorage (100G free
space for 1 year, 2014/5/1 activate) |
| Note |
Support:
Kensington Security Slot.
Padlock Ring
Chassis Intrusion (Optional)
Embedded TPM Security Chip (PRC, RUSSIA excluded)
*1: 8-in-1:SD/SDHC/SDXC/MS/MS PRO/MS PRO HG/MSXC/MMC (Optional
*2
ASUS Business Manager includes Intel SBA & ASUS utilities as following,
Intel PC Health Center, Intel USB locker, Intel Energy Saver, Intel Data Backup &
Restore, Intel Software Monitor, System Maintenance, Update BIOS&Driver
USB lock security, ASUS Secure Delete,Restore&Recovery, Power Saving, My
logo,AI Booting
EPEAT country list please refer to: http://www.epeat.net/ |
