Optical
|
System Specifications
|
Accessories Included
|
Vikuiti™ Super Close Projection
Technology by 3M DMD Panel
.7 in. DLP
|
PC Compatibility
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x
960* (iMAC), 1152 x 870* (MAC), 1024 x 768 (MAC 19")
*resolution digitally compressed
|
1.8m power cord (US, UK, Europe)
1.8m 15 pin D-sub VGA cable
3.5mm audio cable
USB cable
Remote control with batteries
Multi-Language Operator's Guide (CD)
Quick Start Guide
Product Safety Guide
WEEE card (EMEA)
|
Resolution
True XGA (1024 x 768)
|
Video Compatibility
NTSC, PAL, SECAM, 480i/p (1080i), 720p
|
Digital Keystone Correction
Vertical ±40°; Horizontal ±20°
|
Aspect Ratio
4:3 native; 16:9 supported
|
Digital Keystone Correction
Vertical ±16 degrees
|
Audio
4 x 4W SRS WOW™ Technology
|
Contrast Ratio
1600:1
|
Audio Output
Two 2 Watt integrated speakers
|
Startup Screen
Customizable
|
Digital Zoom
100% to 200%
|
Noise Level
Normal 36dB; eco 33dB
|
Noise Level
Normal 39dB; Whisper 33dB
|
Brightness
3000 lumens (maximum rating)
|
Power Consumption
360W (max, <5W eco standby)
|
Horizontal Scan
31.5-106kHz
|
3M Projection
Systems Building A147-5N-01 6801 River Place Blvd. Austin, TX 78726-9000
USA
3M Canada
PO Box 5757 London, Ontario, Canada NGA 4T1
3M Mexico, S.A. de C.V.
Apartado Postal 14-139 Mexico, D.F. 07070 Mexico
© 3M 2009. All rights reserved. Please recycle.
Printed in USA. v09.09
78-6970-8655-7
Limited Warranty
The 3M SCP700 Series projector (the "3M Product") is warranted is warranted to be
free from defects in material or manufacture for a period of three (3) years from
the date of purchase or 4,000 hours of usage, whichever occurs first. All other
accessories of the 3M Product (those in the applicable modular configurations),
excluding the projector lamps, but including the wall mounts, ceiling mounts, digital
annotation sensors, and input/output devices are warranted to be free from defects
in material or manufacture for a period of one (1) year from the date of purchase.
The lamp component of the 3M Product is warranted to be free from defects in material
and manufacture for a period of for a period of ninety (90) days after the date
of purchase of the 3M Product or 180 hours of lamp usage, whichever occurs first.
This warranty is for parts only and in the case of an approved warranty claim for
a lamp, your exclusive remedy will be for a replacement product shipped to your
location. Optional product upgrades and/or accessories that are not sold as part
of any modular configuration are subject to individual warranties.
THE WARRANTIES STATED ABOVE ARE EXCLUSIVE AND ARE MADE IN PLACE
OF ANY AND ALL WARRANTIES, EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR
ANY INDUSTRY PRACTICE OR CUSTOM OR TRADE USAGE. For exclusions, see complete warranty
information at www.3m.com/meetings
3M, and the 3M logo are trademarks of 3M Company. Used under license in Canada. All
other trade names referenced are the service marks, trademarks, or registered trademarks
of their respective companies.
